Product Overview

The CPM-003 is designed for practical electrostatic testing where quick measurements and easy handling are important. Its handheld format allows operators to move between workstations without carrying bulky test equipment.

The meter can be used to check electrostatic field conditions as well as ion balance. Measurement results are presented directly on the LCD screen, making it easier to observe changes during testing and identify areas that may require further ESD control.

Its compact construction also makes it suitable for regular inspection tasks, equipment verification, and maintenance checks in production environments.

Designed for Routine ESD Checks

The CPM-003 combines the main functions needed for everyday static monitoring in one portable unit. The instrument supports automatic range switching between low and high measurement ranges, helping operators handle different testing conditions without manually changing the measurement range.

The display uses different indications for positive and negative charge measurements, allowing the measured polarity to be recognized more easily during operation.

Clear Readout and Simple Operation

The LCD provides a direct view of measurement results and is designed for quick observation during testing. The instrument refreshes the displayed value several times per second, with a response time of approximately one second.

An audible alarm can be used when the measured value exceeds the available range. The unit can also shut down automatically after approximately five minutes of inactivity, helping reduce unnecessary battery consumption.

Measurement Capability

The CPM-003 supports electrostatic field measurements from approximately 0 to ±20.0 kV in automatic range mode. It also provides ion balance measurement within the ±200 V range.

For standard testing, the recommended measurement distance is 25 mm ±1 mm. Measurement accuracy is specified at ±10%, making the unit suitable for routine ESD inspection and workplace monitoring.

Where It Can Be Used

The compact design allows the CPM-003 to be used across different static-control environments, including:

Electronics manufacturing areas

ESD workstations

Electronic assembly lines

Laboratories and R&D facilities

Production workshops

Quality inspection areas

ESD protection equipment checks

Static-control maintenance inspections

Technical Specifications

Model: CPM-003

Power Supply: DC 9V, 6F22 battery

Dimensions: 123 × 73 × 25 mm

Typical Working Time: Approximately 30 hours

Measurement Range: 0 to ±200 V for low range; ±0.01 kV to ±24 kV for high range

Accuracy: ±10%

Measurement Distance: 25 mm ±1 mm

Working Temperature: 0°C to 50°C

Working Humidity: 0 to 60% RH, non-condensing

Display: Red LCD for positive charge and blue LCD for negative charge

Static Field Measurement: ±0.00 to 20.0 kV with automatic range adjustment

Ion Balance Measurement: ±0 to 200 V

LCD Refresh: Approximately 5 updates per second

Response Time: Approximately 1 second

Alarm: Audible alarm for out-of-range conditions

Automatic Power-Off: Approximately 5 minutes without operation

Weight: Approximately 0.17 kg

Portable Design for On-Site Testing

At approximately 0.17 kg, the CPM-003 is easy to carry between testing points. The compact 123 × 73 × 25 mm housing is convenient for storage and routine field inspection, while the included carrying case provides an additional option for transporting the instrument.

Package Contents

The standard package includes the CPM-003 Electrostatic Field Meter, a carrying case, a 9V battery, and packaging.

FAQ

What does the CPM-003 measure?

The CPM-003 is designed to measure electrostatic field conditions and ion balance for ESD monitoring applications.

What is the measurement distance?

The standard measurement distance is 25 mm ±1 mm.

What is the electrostatic field measurement range?

The instrument supports approximately 0 to ±20.0 kV in automatic range mode, with a high measurement range extending to ±24 kV according to the supplied specifications.

Does the meter measure ion balance?

Yes. The CPM-003 provides ion balance measurement within the ±200 V range.

Is the CPM-003 suitable for portable testing?

Yes. Its compact handheld design and approximately 0.17 kg weight make it suitable for moving between workstations and testing locations.

How is the measured value displayed?

Positive and negative charge measurements use different LCD indications to help operators distinguish polarity during testing.

Does it have an automatic shutdown function?

Yes. The instrument automatically powers off after approximately five minutes of inactivity.

What type of battery does it use?

The CPM-003 uses a DC 9V 6F22 battery.

What environments are suitable for the CPM-003?

It can be used for routine ESD checks in electronics manufacturing, laboratories, production areas, workstations, and other static-controlled environments.
