Wide-Area Static Control

The CHUERA-ST028 is designed for applications where static electricity needs to be controlled across a relatively broad working area.

Its horizontal configuration distributes ionized airflow along the work surface, making it suitable for production benches, assembly lines and other areas where several components may need simultaneous static neutralization.

The specified effective coverage is approximately 600 × 1200 mm.

High-Efficiency Ionization

The blower uses AC high-voltage ionization to generate positive and negative ions.

These ions are carried into the working area through the fan airflow, helping neutralize electrostatic charges on products, components and nearby surfaces.

Under the supplied test conditions, the static decay time is no more than 2 seconds at a 300 mm test distance.

Strong Airflow Output

The ST028 provides an airflow range of approximately 70–120 CFM.

The airflow can be adjusted according to the working distance and application requirements. This allows users to balance air movement with the characteristics of the products being processed.

Ion Balance Indication

An ion balance indicator is provided for checking the operating condition of the ionization system.

The specified ion balance is within ±10V when measured at a 300 mm test distance under the stated conditions.

This provides operators with a convenient reference during routine equipment inspection.

Optional Heating Configuration

The ST028 supports an optional warm-air configuration.

The specified power consumption is 50W without heating and 250W when the heating function is included. This provides an additional configuration choice for environments where heated ionized airflow is required.

Adjustable Installation Angle

The horizontal blower supports angle adjustment, allowing the airflow direction to be positioned toward the intended work zone.

This is useful when the installation position or workstation layout changes between different production processes.

Convenient Ion Needle Maintenance

The equipment can be equipped with a dedicated ion needle cleaning device.

Regular cleaning helps remove accumulated contaminants from the ionizing components and supports stable operation over extended periods.

Practical Protection Design

The ST028 includes grounding protection as part of its electrical safety design.

The unit can be installed in a fixed position above or alongside the working area, depending on the layout of the ESD-controlled environment.

Test Performance

The supplied test data was obtained under conditions including humidity below 60%, test voltage from 1KV to 100V and an ambient temperature of 22°C.

At a test distance of 300 mm, the measured positive static decay time is approximately 1.0 second, while the negative decay time is approximately 0.8 second.

At 600 mm, the corresponding values are approximately 1.9 seconds for positive charge and 1.8 seconds for negative charge.

The measured residual voltage is listed as approximately +7V/-7V at 300 mm and +9V/-9V at 600 mm.

Actual performance may differ according to installation distance, airflow conditions, humidity, material properties and other environmental factors.

Technical Specifications

Model: CHUERA-ST028

Input Voltage: 220V/50Hz or 110V/60Hz

Power: 50W without heating; 250W with heating

Ion Output Voltage: AC 5.6kV

Effective Coverage: 600 × 1200 mm

Airflow: 70–120 CFM

Static Decay Time: ≤2 seconds at 300 mm under specified test conditions

Ion Balance: ≤±10V at 300 mm

Ozone Concentration: ≤0.03 ppm at 150 mm

Working Temperature: 0°C–50°C

Working Humidity: <75%

Noise Level: 50–65 dB

Weight: Approximately 3.7 kg

Fan Speed: 3–10 m/s

Housing Dimensions: Approximately L450 × W210 × H190 mm including bracket

Ion Needle Length: Approximately L390 × W210 × 115 mm without bracket

Surface Finish: Electrostatic powder coating

Application Areas

The ST028 can be used where broad-area static control is required, including:

• Electronics assembly lines

• PCB and SMT work areas

• Semiconductor handling

• Precision component production

• Optical assembly

• ESD inspection stations

• Plastic component processing

• Automated production equipment

• Laboratory work areas

• Static-sensitive material handling

Installation and Maintenance

For effective static neutralization, the blower should be positioned so that the ionized airflow reaches the intended working zone.

The actual installation distance should be determined according to the production environment and verified through on-site testing.

The ionizing section, fan grille and airflow path should be inspected periodically. Cleaning frequency can be adjusted according to dust levels, operating hours and workplace conditions.

Product Highlights

• Horizontal structure for wider working-area coverage

• 600 × 1200 mm specified effective range

• 70–120 CFM airflow

• AC 5.6kV ion output

• Ion balance indication

• Adjustable installation angle

• Optional heating function

• Dedicated ion needle cleaning option

• Static decay performance within 2 seconds at 300 mm under specified conditions

• Grounding protection

• Suitable for continuous ESD control

FAQ

What is the CHUERA-ST028 used for?

The ST028 is designed to neutralize static electricity across a relatively wide working area using ionized airflow.

What is the effective coverage of the ST028?

The specified effective coverage is approximately 600 × 1200 mm.

What airflow does the ST028 provide?

The specified airflow range is approximately 70–120 CFM.

Does the unit support heating?

Yes. The ST028 can be configured with an optional heating function. Power consumption is specified as 50W without heating and 250W with heating.

Can the installation angle be adjusted?

Yes. The unit supports angle adjustment so that the ionized airflow can be directed toward the required working area.

Does the ST028 provide ion balance monitoring?

Yes. An ion balance indicator is included, with a specified balance of within ±10V at a 300 mm test distance.

How fast can the ST028 neutralize static charge?

Under the supplied test conditions, the positive decay time is approximately 1.0 second and the negative decay time approximately 0.8 second at 300 mm.

Is an ion needle cleaning device available?

Yes. A dedicated ion needle cleaning device is available for convenient maintenance of the ionizing components.

What power supply does the ST028 use?

The specified input options are 220V/50Hz or 110V/60Hz.

Where is the ST028 suitable for use?

It can be used in electronics manufacturing, PCB and SMT production, semiconductor handling, precision assembly, optical production and other ESD-sensitive work environments.
