Product Overview

The CHUERA C601/C602/C603 series is built for production areas where static electricity needs to be controlled over a defined working zone.

Three configurations are available to accommodate different coverage requirements. The compact C601 is suited to smaller areas, while the C602 and C603 extend the working width with additional fan units.

The equipment combines ionization, airflow and monitoring functions in one enclosure, making it suitable for production lines that require continuous electrostatic control.

Coverage Options for Different Work Areas

The series provides three configurations:

C601: 400 × 600 mm effective coverage, 20W power and approximately 2.56–4.07 m³/min airflow.

C602: 400 × 800 mm effective coverage, 30W power and approximately 2.56–4.07 m³/min airflow.

C603: 400 × 1000 mm effective coverage, 40W power and approximately 2.56–4.07 m³/min airflow.

This range allows the equipment configuration to be matched with different workstation widths and production layouts.

Static Neutralization Performance

The ionizing fan generates ions that help neutralize electrostatic charges around the working area.

Under the specified test conditions, the series achieves a static decay time of no more than 2 seconds at a test distance of 300 mm. Actual results can vary with installation position, environmental conditions and the characteristics of the material being treated.

Ion Balance Monitoring

Ion balance is continuously monitored during operation.

The specified ion balance is within ±10V at the 300 mm test distance. This provides operators with a practical reference for checking whether the ionization system is operating within the required range.

Adjustable Operating Settings

The equipment provides configurable operating parameters for different production conditions.

Cleaning settings can be adjusted within a 0–999-hour range, allowing users to establish a maintenance interval according to operating frequency and workplace requirements.

Clear Equipment Status Display

A built-in display provides operating information directly on the unit.

The interface can be used to check fan operation, high-voltage status, cleaning interval settings, airflow-related information and other operating conditions.

This reduces the need to rely on separate instruments for routine equipment checks.

Maintenance-Friendly Fan Structure

The front and rear fan covers use a snap-on structure.

The design allows the covers to be removed more easily for cleaning and inspection. Standard hanging brackets are also available for installation where overhead positioning is required.

Filter and Ion Needle Maintenance

The unit is designed with replaceable maintenance components, including filter elements and tungsten ion needles.

Regular cleaning and timely replacement of these parts can help maintain normal airflow and ionization performance during continued operation.

Low-Ozone Design

The series is specified with low ozone concentration during operation.

The C601 is rated at no more than 0.01 ppm, the C602 at no more than 0.02 ppm, and the C603 at no more than 0.03 ppm.

These values provide useful reference data when selecting equipment for enclosed or controlled production environments.

Construction and Installation

The elongated enclosure is suitable for installation above workstations and along production areas requiring wider static protection.

Depending on the selected model, the housing dimensions are approximately:

C601: L145 × W72 × H215 mm

C602: L500 × W150 × H82 mm

C603: L700 × W150 × H82 mm

Standard hanging accessories can be used where suspended installation is required.

Technical Specifications

Product Series: CHUERA-C601 / C602 / C603

Product Type: Intelligent High-Frequency Ionizing Fan

Effective Coverage: 400 × 600 mm, 400 × 800 mm or 400 × 1000 mm depending on model

Power: 20W / 30W / 40W

Airflow: Approximately 2.56–4.07 m³/min per fan

Ozone Concentration: ≤0.01 ppm / ≤0.02 ppm / ≤0.03 ppm depending on model

Static Decay Time: ≤2 seconds under specified test conditions

Ion Balance: Within ±10V at 300 mm test distance

Input Voltage: 220V 50Hz / 110V 60Hz

Working Temperature: 0°C to 60°C

Working Humidity: ≤90%

Noise Level: 40–55dB

Cleaning Setting: 0–999 hours

Key Product Benefits

• Three coverage configurations for different work areas

• Fast static charge neutralization

• Ion balance monitoring

• Built-in operating status display

• Adjustable cleaning interval

• Snap-on front and rear fan covers

• Replaceable filter and tungsten ion needle components

• Low-ozone operation

• Standard hanging mounting accessories

• Suitable for continuous ESD control

Recommended Applications

The C601/C602/C603 series can be used in production environments where electrostatic buildup may affect products or processes.

Typical applications include electronics assembly, PCB production, semiconductor handling, precision component manufacturing, optical assembly, laboratory workstations and other ESD-sensitive operations.

The different coverage widths make the series suitable for both individual workstations and longer production areas.

Selection Guide

The model can be selected according to the required working width.

The C601 provides a 400 × 600 mm coverage area and is suitable for relatively compact workstations.

The C602 extends the effective coverage to 400 × 800 mm for wider working areas.

The C603 provides 400 × 1000 mm coverage and is intended for applications requiring a broader static elimination zone.

FAQ

What is the difference between C601, C602 and C603?

The three models mainly differ in power, enclosure size and effective coverage. C601 covers 400 × 600 mm, C602 covers 400 × 800 mm, and C603 covers 400 × 1000 mm.

How quickly does the series neutralize static electricity?

The specified static decay time is no more than 2 seconds when tested at a distance of 300 mm under the stated test conditions.

What is the ion balance specification?

The ion balance is specified within ±10V at a 300 mm test distance.

Can the cleaning interval be configured?

Yes. The cleaning setting can be configured within a range of 0–999 hours.

Does the unit display operating information?

Yes. The built-in display provides information related to equipment operation, including fan status, high-voltage status and cleaning settings.

Are replacement parts available for maintenance?

The structure includes replaceable filter components and tungsten ion needles to facilitate routine maintenance.

Can the ionizing fan be suspended above a workstation?

Yes. Standard hanging mounting accessories are available for overhead installation.

What power supply does the series use?

The equipment supports 220V 50Hz and 110V 60Hz power supply options.

What environments are suitable for this series?

The C601/C602/C603 series is suitable for electronics, semiconductor, precision assembly, optical manufacturing and other production areas where electrostatic control is required.

How should I choose between the three models?

Selection can be based on the required coverage area. C601 is intended for a 400 × 600 mm area, C602 for 400 × 800 mm, and C603 for 400 × 1000 mm.
